Picanol Optimax 4R Looms

Quantity: 20
Year: 2013-2014
2200 mm weaving width / FREE FLIGHT weft insertion type
STAUBLI Dobby S3060 (dobby capacity 20 shafts)
8 sets with 14 shafts + 14 levers + 8 heald frames (14/14/8 installed)
12 sets with 12 shafts +12 levers + 8 heald frames (12/12/8 installed)
4 weft feeders
Machines originally 4 colors (plate) but factory will supply 6 colors installed (fingers).
17 warp beams (1100 mm flange), 13 warp beams (1000 mm flange)
Average: 1.5 beams/machine
Per loom:
8 heald frames / 6000 heddles / 6000 droppers
External batching with FORMIA-GAP inspection table
1 reed per loom

Machines stopped at the moment, still connected to power.
