CAT G 3516H Generators

Quantity: 20
G3512H GAS engine and Caterpillar alternator.
400V, 50 HZ , Operating at 1500 RPM.
1500 KW
Standard OPERATION

1. Design:
These generating sets have been designed to operate continuously under site conditions of -10 to 55 deg. C.

2. Standards:
Our complete range of generating sets comply with the latest British and European standards. When requested a Lloyds, SGS or Cotecna Certificate of Quality will be issued.

3. 20 x 1500 KW Standard Generating Set:

3 . 1 Engine:
Manufacturer : Caterpillar
Model : G3512H
Output : 1484 kWm Prime at 1500 RPM
: 1632 kWm Standby at 1500 RPM
Capacity : 59 litres
Cylinders : 12
Cycle : 4 Stroke
Aspiration : Turbo + AC
Comp Ratio : 13.6 :1
Bore : 170 mm
Stroke : 215mm
Governor : Electronic
Start : Electric Start
Cooling : Tropical Radiator
Flywheel : Heavy Duty
Filtration : Air, Fuel and Oil
Instruments : Oil Pressure Gauge, Water Temperature Gauge
Battery Charge Ammeter

3 . 2 Alternator:
Manufacturer : Caterpillar
Model : Kato
Output : 1854 KVA Prime at 1500 RPM
2039 KVA standby at 1500 RPM
Voltage : 400V, 3 Phase, 50 Hz, 0.8 PF
Type : Brushless
Self-exciting
Automatic voltage regulation
Tropicalised
Insulation : Class H
Temperature rise : Class H
Degree of Protection : IP23

4. Standard Control Panel:
1500 kW Generating set
EMCP 4.3
MCCB Circuit Breaker, 3 Pole, 400 KVA

5. Accessories:
5 . 1 Base tank
5 . 2 Silencer
A silencer is included
5 . 3 Electric Start
A 24V electric starting system is supplied
5 . 4 Vibration Dampers
A set of vibration dampers are fitted to the generating sets.
5 . 5 Documentation
The following set of documentation will be supplied with each set :-

Operating manual
Maintenance manual
Wiring diagram
Test Certificate
Guarantee Certificate
